Ikeda IST-201 MC Step-Up Transformer/26D. Product of the Year. Handmade in Japan

Now at True Audiophile

We listened to a lot of phono stages and it takes a lot for us to be impressed. This Ikeda does that brilliantly. Now being awarded Product of the Year, its a no brainer when you want a SUT... Mini Review by True Audiophile

The newly developed Step-Up transformer IST-201 is best suitable for low impedance 1ohm - 6ohm MC cartridges. These low impedance cartridges will be able to work at their full potential by virtue of this high quality MC transformer.

IST-201 is the ideal transformer with a lesser internal loss so that you will be able to enjoy a supreme sound in combination with IKEDA 9 series and our flagship KAI cartridges as well as other brands of low impedance cartridges.

The body of the transformer is made of high efficiency core materials and magnetic shielding technology using MU-Metal with a high shielding rate. In addition, the body of the transformer is embedded and perfectly shielded within the large shielded chassis with high electrical conductivity.

In order to attain the highest resolution efficiency and to improve the characteristics, the highly accurate VISHY|S-102K is used for the terminators in the secondary side of the transformer. The terminators are very reliable for all connecting cables used and stable for fluctuation of the load impedance.

The integrally matching RCA connectors made with rhodium plating are mounted on the insulating plate so that a weak signal from MC cartridges shall be protected by this architecture.

Also featuring a floating earth switch on rear panel.

[[[specification_start]]]

Product Specifications:

Model:
Step-Up Transformer for MC cartridges

Input Impedance:
2 ohm - 6 ohm

Load Impedance:
Over 47k ohm

Channel Separation:
Over 90dB (1kHz)

Frequency Response:
10Hz - 100kHz, ±0.6dB, 3ohm/47k ohm

Step-Up Rate:
26dB

Channel Balance:
Within 0.1dB (1kHz)

Dimensions:
5.5 x 3.7 x 2.2" (WxDxH)

Weight:
3.74 lbs.
